SmartNet - Satellite Positioning Service

Delivering the most accurate and comprehensive coverage.

MGISS offer two positioning services: HxGN SmartNet which provides UK and Ireland coverage; and Atlas which offers worldwide coverage.

Using our data-enabled multi-network SIM card, you can achieve complete coverage across all mobile networks.

The densest reference station in the UK.

SmartNet is the first commercial GNSS (Global Navigation Satellite System) Network based on raw data from the Ordnance Survey GNSS networks in both Great Britain & Ireland. This network comprises around 150 sites, including additional sites from Leica Geosystems permanent nationally deployed GPS reference stations.

Leica SmartNet provides an RTK and DGPS correction service for any professional with a GPS receiver that can accept RTK or DGPS corrections broadcast by GSM or GPRS. So, whether you own a Leica Geosystems GNSS receiver or any other make of GNSS receiver you can benefit from the densest reference station in the UK.

A Network RTK solution combines observation data at base stations and at the Rover to generate RTK corrections for the Rover’s location.A user subscribes to the service by dialling in through the internet, to receive RTK corrections to their Rover. These RTK corrections can be generated by more than one method: Master-Auxiliary corrections (MAX), Individualised MAX (i-MAX) and Virtual Reference Station (VRS).

Network RTK:

  • Horizontal accuracy of 1-3 cm for all sensors / 0.8 cm for Leica Geosystems GS sensors.
  • Vertical accuracy of 2-5 cm for all sensors / 1.5 cm for Leica Geosystems GS sensors.

RTK Bridging:

  • 5 cm horizontal accuracy.
  • 5 cm vertical accuracy.

Precise Point Positioning:

  • 5 cm horizontal accuracy.
  • 5 cm vertical accuracy.



  • No substantial purchase costs of a GNSS base station.
  • No time lost establishing a local reference receiver.
  • No security concerns at the reference station site.
  • SmartNet is available nationwide.
  • Guaranteed quality assurance and traceability.
  • Free of charge SmartRINEX download facility for post-processing

GNSS (Global Navigation Satellite System) is a general term describing any satellite constellation that provides positioning, navigation and timing services worldwide. GNSS receivers (including many mobile phones) receive radio signals from these satellites and GNSS positioning works by simple triangulation. Because we know the speed of a radio signal (speed of light), your receiver can compare the device time at the point it receives the signal to that of the time-stamped signal to provide the time it has taken to travel to the receiver. Knowing speed and time, the receiver can therefore calculate the distance to each satellite using the Distance = Speed * Time calculation. The receiver then uses the principle of triangulation (using 3 or more satellite distances) to calculate your accurate position on the Earth’s surface.

How accurate depends on a few factors. An uncorrected position, as calculated by your phone, will position you with an accuracy of around 6 meters. This does not sound great however for the purposes of something like satnav this is good enough to position you on the correct road. If, however, you are a surveyor, Asset Capture would need to involve a more accurate position to underpin Asset Location. The asset could be a water valve which has been buried, overgrown or even flooded. If an operative needs to close that valve, then the minimum requirement would be to use accurate Asset Location to find and turn it off.

The reason a mobile phone can currently only provide accuracies of around 6m is that most cannot use all the GNSS constellations, and they cannot recognise and reject inferior quality signals, such as those reflected from other surfaces. These are called multipath signals and, because they are indirect, they will position you incorrectly.

Currently, the most accurate GNSS positioning systems require specialist 3rd party receivers, such as those provided by Eos Positioning Systems and Leica.

These can easily be ‘plugged in’ to existing phones and tablets as they already have the required multipath rejection technology and can track additional satellite constellations for higher accuracy including the SBAS (Satellite Base Augmentation System). This combination can underpin a much more accurate Asset Capture experience by providing sub-meter accuracies.

If your work mandates even higher precision, then you can also plug in RTK (Real Time Kinematic) correction services, such as Leica Smartnet. RTK provides connection to a network of base stations which are surveyed to the millimetre to provide further corrections live in the field. This can add the power of cm-level accuracy to your Asset Capture system and is well within NRSWA 300mm or PAS256 100mm standards.

Interested in SmartNet pricing?


FAQs

Yes, you can. SmartNet will work with any Leica Geosystems GPS/GNSS receiver or any other make of GPS/GNSS receiver.

You can use the HxGN SmartNet correction service anywhere in the UK and Ireland.

SmartNet covers UK & Ireland, while Atlas provides global coverage.
